ADM1026
Table 13. LIST OF REGISTERS
Hex
Address
23
24
25
26
27
28
29
2A
2B
2C
2D
2E
2F
30
31
32
33
34
35
36
37
38
39
3A
3B
3C
3D
3E
3F
40
41
42
43
44
45
46
47
48
49
4A
4B
4C
4D
4E
4F
50
51
Name
Status Register 4
Status Register 5
Status Register 6
V BAT Value
A IN8 Value
TDM1 Value
TDM2/A IN9 Value
3.3 V STBY Value
3.3 V MAIN Value
+5.0 V Value
V CCP Value
+12 V Value
? 12 V Value
A IN0 Value
A IN1 Value
A IN2 Value
A IN3 Value
A IN4 Value
A IN5 Value
A IN6 Value
A IN7 Value
FAN0 Value
FAN1 Value
FAN2 Value
FAN3 Value
FAN4 Value
FAN5 Value
FAN6 Value
FAN7 Value
TDM1 High Limit
TDM2/A IN9 High Limit
3.3 V STBY High Limit
3.3 V MAIN High Limit
+5.0 V High Limit
V CCP High Limit
+12 V High Limit
? 12 V High Limit
TDM1 Low Limit
TDM2/A IN9 Low Limit
3.3 V STBY Low Limit
3.3 V MAIN Low Limit
+5.0 V Low Limit
V CCP Low Limit
+12 V Low Limit
? 12 V Low Limit
A IN0 High Limit
A IN1 High Limit
Power-on
Value
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
00h
64h (100 ? C)
64h (100 ? C)
FFh
FFh
FFh
FFh
FFh
FFh
80h
80h
00h
00h
00h
00h
00h
00h
FFh
FFh
Description
Interrupt status register for local temp, V BAT , A IN8 , THERM, AFC, CI, and GPIO16.
Interrupt status register for GPIO0 to GPIO7.
Interrupt status register for GPIO8 to GPIO15.
Measured value of V BAT .
Measured value of A IN8 .
Measured value of remote temperature channel 1 (D1).
Measured value of remote temperature channel 2 (D2) or A IN9 .
Measured value of 3.3 V STBY.
Measured value of 3.3 V MAIN.
Measured value of +5.0 V supply.
Measured value of processor core voltage.
Measured value of +12 V supply.
Measured value of - 12 V supply.
Measured value of A IN0 .
Measured value of A IN1
Measured value of A IN2 .
Measured value of A IN3 .
Measured value of A IN4 .
Measured value of A IN5 .
Measured value of A IN6 .
Measured value of A IN7 .
Measured speed of Fan 0.
Measured speed of Fan 1.
Measured speed of Fan 2.
Measured speed of Fan 3.
Measured speed of Fan 4.
Measured speed of Fan 5.
Measured speed of Fan 6.
Measured speed of Fan 7.
High limit for Remote Temperature Channel 1 (D1) measurement.
High limit for Remote Temperature Channel 2 (D2) or A IN9 measurement.
High limit for 3.3 V STBY measurement.
High limit for 3.3 V MAIN measurement.
High limit for +5.0 V supply measurement.
High limit for processor core voltage measurement.
High limit for +12 V supply measurement.
High limit for - 12 V supply measurement.
Low limit for Remote Temperature Channel 1 (D1) measurement.
Low limit for Remote Temperature Channel 2 (D2) or A IN9 measurement.
Low limit for 3.3 V STBY measurement.
Low limit for 3.3 V MAIN measurement.
Low limit for +5.0 V supply.
Low limit for processor core voltage measurement.
Low limit for +12 V supply measurement.
Low limit for - 12 V supply measurement.
High limit for A IN0 measurement.
High limit for A IN1 measurement.
http://onsemi.com
